CURT 16181 A25 5th Wheel Hitch with Base Rails; 25;000 lbs

---

The CURT A25 5th wheel hitch offers smoother, quieter towing for your home-away-from-home, combining the patented technology of our A-series, an easier mounting system and the power of a 25K 5th wheel hitch. Like our A16 and A20 hitches, this 25K 5th wheel hitch uses a patented cast yoke to allow for unimpeded head movement, while providing exceptional stability for the trailer. The yoke has a set of poly-torsion inserts to suppress shock loads and reduce excessive noise, and the head features high-strength, interlocking jaws to give the trailer stability and the freedom to pivot and swivel as needed. The A25 5th wheel hitch is also engineered for easier installation. The legs are equipped with two pins to properly align with the mounting holes, and they have easy-access mounting bolts for ergonomic tightening. The 5th wheel head also has a fast, one-pin removal system to make installation and removal from the truck bed easier. This 25K 5th wheel includes a set of industry-standard 5th wheel base rails to mount onto custom 5th wheel brackets. Once installed, the A25 is fast and simple to operate. It features an extra-wide head opening to increase the coupling area for the trailer, and it has a lockable, single-throw handle that self-resets to the ready-to-couple position after uncoupling. To make coupling even easier, it is equipped with a coupling indicator that is visible from the truck cab. The indicator shows the status of the connection and eliminates the need for you to check multiple times while coupling. To protect the A25 5th wheel hitch against rust, wear and whatever other threats might impede your cross-country tour, it comes with a carbide black powder coat finish and a limited lifetime warranty. We also test the A25 for safety in accordance with SAE J2638 to ensure reliability for the road ahead.

• Cast Yoke w/Poly-Torsion Inserts To Suppress Shock And Noise
• Extra-Wide Head Opening For Easier Coupling
• Fast One-Pin Head Removal Makes Moving The Hitch Easy
• Three-Position Coupling Indicator Is Visible From The Truck
• Three Height Adjustments Positions To Adapt To Truck Bed
• Compatible w/Kingpin Extension Incl. Common Pivoting Pin Boxes
• Incl. A Polyethylene Lube Plate To Eliminate Messy Grease Deposit
• Alignment Pegs And Easy-Access Bolts For Simple Attachment
• Articulating Torsion Head; Controlled Coupling And Stable Towing
• Lockable Handle Self-Resets To The Ready-To-Couple Position
• Constructed w/Cast Steel Main Body For More Precise Build
• High-Strength Interlocking Jaw Wrap The Kingpin To Minimize Noise

---

Information:

A25 5th Wheel Hitch with Rails; Cast yoke with poly-torsion inserts to suppress shock loads and reduce noise; Fully articulating torsion head for controlled coupling and stable towing; Lockable handle self-resets to the ready-to-couple position after uncoupling; Constructed with a cast steel main body for a more precise build; High-strength, interlocking jaws fully wrap the kingpin to minimize noise; Extra wide head opening for easier coupling; Fast, one-pin head removal makes moving easy with smaller, lighter pieces; Alignment pegs and easy-access bolts for simple leg-to-body attachment; Three-position coupling indicator clearly shows coupling status; Compatible with kingpin extension boxes, including common pivoting pin boxes; Offers three height adjustment positions to adapt to each unique truck bed; Includes a polyethylene lube plate to eliminate messy grease deposits; Tested for safety in accordance with SAE J2638; Protected by a highly durable carbide powder coat finish; Limited lifetime warranty (one-year finish, one-year parts); Patent# 8,827,298

---

Application Summary:

Year	Make/Model
1999-2016	Chevrolet Silverado 1500
2007	Chevrolet Silverado 1500 Classic
2001-2003	Chevrolet Silverado 1500 HD
2005-2006	Chevrolet Silverado 1500 HD
2007	Chevrolet Silverado 1500 HD Classic
1999-2004	Chevrolet Silverado 2500
2001-2016	Chevrolet Silverado 2500 HD
2007	Chevrolet Silverado 2500 HD Classic
2001-2006	Chevrolet Silverado 3500
2007	Chevrolet Silverado 3500 Classic
2007-2016	Chevrolet Silverado 3500 HD
2002-2010	Dodge Ram 1500
2003-2010	Dodge Ram 2500
2003-2010	Dodge Ram 3500
1997-2014	Ford F-150
2004	Ford F-150 Heritage
1997-1999	Ford F-250
1997	Ford F-250 HD
1999-2016	Ford F-250 Super Duty
1999-2016	Ford F-350 Super Duty
1999-2014	GMC Sierra 1500
2007	GMC Sierra 1500 Classic
2001-2003	GMC Sierra 1500 HD
2005-2006	GMC Sierra 1500 HD
2007	GMC Sierra 1500 HD Classic
1999-2004	GMC Sierra 2500
2001-2015	GMC Sierra 2500 HD
2007	GMC Sierra 2500 HD Classic
2001-2006	GMC Sierra 3500
2007	GMC Sierra 3500 Classic
2007-2015	GMC Sierra 3500 HD
2004-2012	Nissan TITAN
2011-2016	Ram 2500
2011-2016	Ram 3500
2000-2014	Toyota Tundra
