CURT 15704 Commercial Duty Class 5 Trailer Hitch, 2-1/2-Inch Receiver, Compatible with Select Dodge Ram 1500, 2500, 3500
In the world of commercial towing, more is expected. A job cannot be completed if the equipment cannot handle the workload. That is why CURT developed the Commercial Duty class 5 trailer hitch. Constructed from steel and engineered for power, these class 5 hitches are designed to complement the towing power of full-size, commercial pickup trucks, including diesels and chassis cabs. They can easily handle a variety of oversize trailers, including toy and car haulers, livestock trailers, dumper trailers, large flatbed trailers, large boat trailers and more (NOTE: Never exceed the lowest weight capacity of any towing component). This particular class 5 hitch features a gross trailer weight capacity of 18,000 lbs. and a tongue weight capacity of 2,700 lbs. It is designed to be a custom trailer hitch for certain years of the Dodge Ram 1500, 2500 and 3500 (to verify your vehicle compatibility, see application info). All CURT Commercial Duty class 5 hitches feature a 2-1/2" x 2-1/2" receiver tube opening to accept the strongest of ball mounts and towing accessories. They are perfect for mounting standard ball mounts, pintle mounts, tow hooks and weight distribution hitches as well as winch mounts and cargo carriers. CURT class 5 tow hitches are protected by a co-curing of liquid A-coat and carbide black powder coat finish. They also mount with grade-8 hardware, included with each hitch.
- Rated to 18,000 lbs. gross trailer weight and 2,700 lbs. tongue weight
- Protected by a highly durable carbide powder coat finish
- Co-cured in a rust-resistant liquid A-coat, inside and out
- Features wide safety chain openings for heavy-duty hooks
- Equipped with an open-back receiver for easy cleaning
- Limited lifetime warranty (one-year finish, one-year parts)
- Made in USA (may include imported hardware)
- Compatible with weight distribution hitch (18,000 lbs. WD / 2,700 lbs. WDTW)
- Engineered with a vehicle-specific design for a custom fit
- Tested for safety in accordance with SAE J684
- Precisely welded for superior strength and fit
- Constructed with a large, powerful main body
Information:
Constructed with a large, powerful main body
Application Summary:
| Year |
Make/Model |
| 2003-2008 |
Dodge Ram 1500 |
| 2003-2010 |
Dodge Ram 2500 |
| 2003-2010 |
Dodge Ram 3500 |
| 2011-2015 |
Ram 2500 |
| 2011-2015 |
Ram 3500 |
| Attributes |
| ASIN |
B00C0LJHA6 |
| Attachment Location |
Rear |
| Body Shape |
Square |
| Box Height in Inches - XA |
33, 33 |
| Box Length in Inches - XA |
48, 48 |
| Box Width in Inches - XA |
14, 14 |
| California Proposition 65 |
Yes |
| Class ID |
10, 10 |
| Color |
Black |
| Container Volume Cubic Feet - XA |
0.00000, 0.00000 |
| Container Volume Cubic Meter - XA |
0.00000, 0.00000 |
| Country of Origin (Primary) |
US |
| Drilling Required |
No, No |
| Finish |
Carbide Black Powder Coat, Powder Coated |
| Finish - XA |
CARBIDE BLACK POWDER COAT |
| GTIN |
00612314157044 |
| Gross Trailer Weight |
18000 lbs. |
| Gross Trailer Weight (lbs.) |
18000 |
| Harmonized Tariff Code (Schedule B) |
8708998180 |
| Hazardous Material Code |
N |
| Hitch Class |
V |
| Install Time |
30 Minutes |
| Item Class - XA |
MFH, MFH |
| Item Height - XA |
11.100, 11.100 |
| Item Length - XA |
41.500, 41.500 |
| Item Width - XA |
28.310, 28.310 |
| Life Cycle Status Code |
Available to Order |
| Long Description |
Class V Trailer Hitch |
| Main Body Shape |
Square, Square |
| Master Case Height Inches - XA |
0.000, 0.000 |
| Master Case Length Inches - XA |
0.000, 0.000 |
| Master Case Volume Cubic Feet - XA |
0.00000, 0.00000 |
| Master Case Weight Lbs - XA |
0.000, 0.000 |
| Master Case Width Inches - XA |
0.000, 0.000 |
| Material - XA |
Carbon Steel, Carbon Steel |
| Mount Type Description - XA |
Blank, Blank |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Pallet Qty - XA |
10.000, 10.000 |
| Pallet Total Height Inches - XA |
0.000, 0.000 |
| Pallet Total Weight Per - XA |
0.000, 0.000 |
| Parcel Allowed - XA |
Yes, Yes |
| Position |
Rear |
| Price Code - XA |
97, 97 |
| Product Weight - XA |
77.000, 77.000 |
| Rate Class - XA |
70.0, 125.0 |
| Receiver Included |
No |
| Receiver Size |
2 |
| Receiver Tube Size |
2-1/2 IN, 2.500 in. |
| Retail Height - XA |
0.000, 33.630 |
| Retail Length - XA |
0.000, 48.500 |
| Retail Width - XA |
0.000, 14.500 |
| SDR Required Flag |
N |
| Sales Family Code - XA |
HITCH, HITCH |
| Sales Family Description - XA |
HITCH, HITCH |
| Sales Group Description - XA |
CL 5, CL 5 |
| Shipping Weight - XA |
84.700, 86.000 |
| Side Application Type Description - XA |
Blank, Blank |
| Tariff 301 - XA |
No, No |
| Tongue Weight (TW) |
2,700 LB, 2,700 LB |
| Tongue Weight(TW) |
2,700 LB |
| Truckload Volume Cubic Feet - XA |
0.00000, 0.00000 |
| Visibility |
Exposed |
| WC Tongue Weight |
2700 |
| WD Tongue Weight |
2700 |
| Warranty |
Limited Lifetime Warranty (One-Year Finish, One-Year Parts), Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
| Weight Carrying Capacity |
18000 |
| Weight Carrying Capacity (WC) |
18,000 LB, 18,000 LB |
| Weight Carrying Capacity(WC) |
18,000 LB |
| Weight Distribution |
18000 |
| Weight Distribution (WD) |
18,000 LB, 18,000 LB |
| Weight Distribution Tongue Weight (WDTW) |
2,700 LB, 2,700 LB |
| Weight Distribution Tongue Weight(WDTW) |
2,700 LB |
| Weight Distribution(WD) |
18,000 LB |
